Pallet dimensions often refer to the pallet footprint. When booking freight, you need to enter the dimensions of the complete shipment, including pallet, goods and packaging. Here you will find the dimensions and weight of the most common pallets and how to measure correctly.
Pallet dimensions in a table
| Pallet type | Dimensions (cm) | Height | Own weight | Also called |
|---|---|---|---|---|
| Euro pallet / full pallet | 120 × 80 | 14.4 cm | about 25 kg | EUR pallet, EPAL pallet |
| Half pallet | 80 × 60 | XX | XX | – |
| Quarter pallet | 60 × 40 | XX | XX | – |
| Industrial pallet | 120 × 100 | XX | XX | EPAL 2 |
| One-way pallet | varies | varies | varies | – |
The dimensions are footprints. Height and weight vary between models, so always check the pallet you are using.
Euro pallet dimensions
A Euro pallet, also called a EUR pallet or full pallet, measures 1,200 × 800 mm (120 × 80 cm) and is 144 mm high. Correct construction and EUR marking decide whether the pallet meets the standard. To send a Euro pallet, compare prices when you send pallets with Shiplink.
Half pallet dimensions
A half pallet usually measures 800 × 600 mm (80 × 60 cm), half the Euro pallet footprint. Height, material and construction can vary between models. Read more about how to send a half pallet.
Quarter pallet dimensions
A quarter pallet measures 600 × 400 mm (60 × 40 cm), a quarter of the Euro pallet footprint. It suits smaller shipments that do not need a half pallet.
Industrial pallet dimensions
An industrial pallet, also called EPAL 2, measures 1,200 × 1,000 mm (120 × 100 cm). It is wider than the Euro pallet. Other models and formats are also used.
One-way pallet
A one-way pallet has no single standard size. It may have the Euro pallet footprint or be tailored to a particular load. Check the dimensions of the pallet you are using.
How much does a Euro pallet weigh?
A Euro pallet weighs about 25 kg. The exact weight depends on construction, condition and moisture content. The maximum load is XX kg. Remember that the total weight when booking is the pallet, goods and packaging together. A shared footprint does not mean that different pallet models weigh the same or have the same load capacity.
How to measure the complete shipment
Pallet footprint and overall shipment dimensions
A EUR pallet may have a 120 × 80 cm footprint while the packed shipment is wider because of protruding goods or packaging. The pallet’s own height is also included in the total shipment height. Use the packed load as your starting point and check that the complete shipment meets the selected service’s specifications.
Length, width and height
- Length: measure the shipment’s longest horizontal dimension between its outermost points.
- Width: measure the other horizontal dimension, including anything that protrudes.
- Height: measure from the underside of the pallet to the shipment’s highest point, including top protection and other packaging.
Shiplink’s portal always uses centimetres. Measure each piece if a shipment contains several pallets of different sizes.
Worked example: enter the total height
Illustrative example, not a service limit: a pallet is 15 cm high. The goods and packaging together rise 100 cm above its top surface. The total shipment height is therefore 15 + 100 = 115 cm.
Enter 115 cm in the height field, not 100 cm. If top protection is added beyond those 100 cm, include that too. Measure the packed shipment to check the result; actual pallet heights vary.
Overhang
Overhang means that goods or packaging extend beyond the pallet edges. It is possible, and sometimes it is the best way to pack, but it increases the risk of damage and must be included in the overall dimensions. Overhang often affects service choice and price. Read more about what affects pallet shipping costs.
Stackability
Stackability is a separate booking detail. A flat top or a particular pallet format does not automatically make the shipment stackable. The requirements are covered in the guide on how to pack a pallet.
Larger shipments
When several pallets go on a truck, the space is often calculated in loading meters or deck space.
Shiplink is a freight platform where businesses can compare and book freight services from multiple carriers. Use actual overall dimensions and total weight when comparing the options. See how to send pallets.
